Flat-End Multilayer Wave Springs
Flat-end multi-layer wave springs also provide a choice of flat-ends. The flat-end allows the high-wave spring to have a 360° contact surface. In the case of force, the flat-end can more evenly distribute the spring force to adjacent components. When the need exceeds 360° °For uniform force distribution and/or rotation pressure, the use of flat ends is ideal for high wave springs.
Model :
平端多層波形彈簧
Flat-end multi-layer wave springs also provide a choice of flat-ends. The flat-end allows the high-wave spring to have a 360° contact surface. In the case of force, the flat-end can more evenly distribute the spring force to adjacent components. When the need exceeds 360° °For uniform force distribution and/or rotation pressure, the use of flat ends is ideal for high wave springs.
Surface: galvanized, nickel-plated, gold-plated, electric painting, phosphate, black dyed, copper-plated, electroless nickel.
Minimum thickness: 0.1mm
Maximum width:
Minimum outer diameter of spring: mm
The smallest possible tolerance value: 0.03mm
The wave spring reduces the working height of the spring by 50%.
It has the same load and deformation as ordinary helical compression springs.
Wave springs are suitable for radial and axial spaces.
